Intek KT-900EE | THUNDERPOLE.co.uk

Intek KT-900EE

Ref: 01KT-900EE
Delivery: Free Delivery in UK Mainland

(Inc. 20% VAT)

	Main Features:
●	Display & keyboard with backlight
●	CTCSS & DCS
●	Wide / Narrow switch
●	Programmable repeater offset (+ / - 0 - 69.9875 MHz)
●	1750 Hz tone
●	VOX function (9 sensitivity levels)
●	Scan function (including CTCSS & DCS scan)
●	Monitor function
●	Digital S-meter
●	Dual Watch function
●	Ring tone function
●	Squelch manually adjustable in 9 steps
●	Roger Beep (switchable)
●	Time-Out Timer function
●	Confirmation tone keypad (disabled)
●	RX / TX LED indicator (green/red)
●	Keypad lock (selectable)
●	Emergency channel programmable
●	APO function
●	Busy Channel Lock Out Function
●	Writable alphanumeric memory channels
●	PC programmable (Interface & Software - optional)
●	FM radio reception in WFM
●	Display battery status
●	Power Save Mode
●	Desktop charger with LED status display



	Intek KT-900EE \| Dual Band VHF/UHF FM Handheld Transceiver The Intek KT-900EE VHF/UHF FM handheld radio is a fully PC programmable (with optional program kit) Dual Band amateur radio with an aluminium diecast chassis.

User Manual

Compatible with Kenwood Wired Microphones

2.5mm & 3.5mm Double Pins

General:
Frequency:	VHF 144-146 MHz (136.000 - 174.9875 MHz) (*)
	UHF 430-440 MHz (400 - 470.9875 MHz) (*)
Channels:	128
Channel Spacing:	5, 6.25, 10, 12.5, 25 KHz
DC Input Volatge:	7.4 VDC
Operating Temperature:	-20/+55
Dimensions:	58 x 95 x 38 mm
Weight:	220 gr. (with battery pack and antenna)
Receiver:
Sensitivity (12dB Sinad):	1.8 μV
Selectivity:	60dB
Audio output:	500mW
Transmitter:
RF output power:	5W / 1W (VHF)
	4W / 1W (UHF)
Modulation:	F3E/F2D
Spurious & Harmonics:	in compliance with the R&TTE regulations
Maximum deviation:	≤ +/- 5KHz / ≤ +/- 2.5KHz
Frequency Stability:	+/- 2.5ppm
FM Radio:
Frequency range:	87.5 - 108 MHz
Frequency Step:	50 KHz
Modulation:	WFM

(*) Model Intek KT-900EE (INTERNATIONAL VERSION)


	Included with your Intek KT-900EE


Intek KT-900EE	1 x 1200 mAH Li-ion Battery Pack	Drop-in Charger (3 hours)	Belt Clip	User Manual
