Intek HR-2800 | 10 Amateur Radio

K-PO HR-2800

Ref: 01HR2800KPO
Delivery: Free Delivery in UK Mainland

Price: £159.99(Inc. 20% VAT)

+ £2.00

	Specifications:
●	Frequency range 28.000 - 29.700 MHz HF 10 Meter Band AM/FM
●	Backlighted LCD Display (amber color) with 5-digit frequency readout
●	ESP COMPANDER (RX/TX modulation speech processor)
●	Digital S/RF Meter
●	RG Gain control, Mic Gain control
●	Scan
●	Dual Watch
●	EMG
●	LCR
●	ANL
●	LOC/DX
●	Dynamic Microphone with UP/DOWN/LOCK controls
●	Quick UP/Quick DOWN frequency selection
●	PA (Public Address) circuit
●	4 + 1 Memory Channels
●	Wide DC Voltage input range (12.0-32.0VDC) with built-in electronic voltage regulator (DC-DC Converter)
●	Mitsubishi RD16HHF1 Mosfet Power RF Transistor
●	AS/SQL (manual or automatic (fixed) Squelch control)



	K-PO HR-2800 \| AM/FM 10 Meter Mobile Amateur Transceiver Amateur radio HF mobile transceiver, covers the 28 MHz frequency band reserved to Amateur Radio communication. Frequency range 28.000-29.700 KHz in 5 KHz frequency steps. Transmitter RF power 20W max in AM and FM modes. Digital ESP (RX and TX Electronic Speech Processor) compresses modulation level in transmission (Compressor) and expands audio modulation in reception (Expander). Large backlighted amber color LCD Display with digital S/RF Meter, shows full 5-digit frequency readout. RF Gain and Mic Gain controls. Programmable 5 + 1 memory channels, LOCAL/DX RF attenuator, manual and automatic (fixed) Squelch control. ANL (Automatic Noise Limiter), SCAN and DW (Dual Watch) functions. High quality Dynamic microphone with UP/DN frequency and LOCK controls. Radio can be powered with 12.0VDC minimum to 32.0VDC maximum, with built-in electronic voltage regulator.

User Manual

More Info

General:
Frequency:	28.000-29.700 MHz HF 10 Meter Band
Operating modes:	FM-AM
Frequency control:	P.L.L.
Operating temperature:	-10°/+55°C
DC input voltage:	12.0VDC (minimum) to 32.0VDC (maximum)
Weight:	1.5 kg
Dimensions:	153 (L) x 50 (H) x 210 (D) mm
Receiver:
System:	Double conversion, CPU controlled super-eterodine
IF:	1° 10.695 MHz / 2° 455 KHz
Sensitivity:	0.5uV for 20dB SINAD (FM
	0.5uV for 20dB SINAD (AM)
Audio Output:	@10% THD 2.5W at 8 ohm
Audio Distorsion:	<8% at 1 KHz
Image Rejection:	65dB
Adjacent channel:	65dB
Signal/noise ratio:	45dB
Current drain:	250mA (stand-by)
Transmitter:
System:	CPU controlled P.L.L. systhesizer
Maximum RF power :	20W
Modulation:	85% to 90% (AM)
	1.8 KHz ±0.2 KHz (FM)
Impedance:	50 ohm unbalanced
Current drain:	6.0A (at no modulation)

HR-2800EX International Version, features additional 11 CB bands (all european and international CB bands) frequency range 25.610- 30.105 KHz. Not available for sale or use in the EEC countries.


K-PO HR-2800	Microphone	Power Lead	Bolts	Bracket	User Manual
